Window EuroVision2 450x500 Black Frame

Our EuroVision 2 Windows range offers ultimate privacy, security and ventilation for all types of Caravan and RV’s.

Built using the same premium high-quality materials as our popular standard EuroVision Window range, the upgraded Slim Blind EuroVision 2 is the new popular design among the Caravanning and RV industry.

This updated EuroVision 2 model has no curtain tracks making the blind even slimmer, giving it a sleek and modern design. It also features the EuroVision 2 flat outer profile and a darker tint.

This high quality, European style window is designed with a screwless clamp providing a simple and secure fixing method. Finished off with UV resistant double-glazed acrylic, internal blind and insect screen, the EuroVision 2 windows are perfect for all conditions on the road.

Features:

• White blind and outer frame
• Built-in internal slim blind
• UV resistant double-glazed acrylic windows
• 24% increase in opening size and ventilation access
• Pull down block out blind with a reflective backing
• Pull down insect blind
• Push button locking handles
• Three stage opening position on all windows
• Equipped with a semi-lock position for ventilation in windy conditions
• Blind system can be activated individually or locked together and positioned as required
• Screwless clamp design provides a simple and secure fixing method
• Black aluminium inner frame
• Suitable for wall thicknesses of 24mm to 34mm
• 12-month warranty

Specifications:

• The size refers to the cut out size of the window rather than the full window itself
• The cut out size is approx. 30mm less than window itself. For example, if you measure your window to be 480x530mm, then the size you require is 450x500mm
• For installation purposes, 25mm clear space must be provided above the top of the blind system and 30mm below blind
• Add 3mm to the height and width of the window for the hole cut out size
• Each Radius measures 68mm
• Please note: EuroVision 2 windows are sold with a standard sized inner frame. If your wall thickness is greater than 35mm you will need to purchase an additional inner frame in a larger size.

Instruction Manuals

Installation Manual

Operation Manual
